- 【High Efficiency】This solar cooker can quickly convert the gathered solar energy into heat energy. It can reach temperatures as high as 1472-1832°F, providing you with up to 1500W of thermal power. This enables it to boil 1kg of water in just 6 to 8 minutes.
- 【Sturdy and Durable】The concentrated solar cooker is made of high-quality iron, which provides excellent toughness, making it durable for long-lasting use. The converging reflector has an aluminium film with a good reflection effect and reliable performance.
- 【Perfect for Outdoor】The solar stove is convenient and economical for cooking in outdoor camping with ample sunshine. It can reach temperatures equivalent to a kitchen oven, and the heat generated can be controlled by adjusting the size of the light spot.
- 【Thoughtful Designs】The stable triangular and cross structure provides you with reliable support. The iron frame surface is sprayed with plastic, making it adaptable to various weather conditions. The three wheels at the bottom make it easy to move around.
- 【Wide Applications】The solar heater is a versatile device that can be used by families, schools, factories, mines, railways, train stations, geological exploration teams, on-site operation crews, tourists, picnickers, catering industry and street food stalls.
How to Use
1. Select a flat ground, carry the six light collecting plates downward into a circle, and then use M6X 15 round-head screws to form a whole of the six light collecting plates and tighten the screws. (The screw holes on the third circle from the inside to the outside are used to fix the square tube ring. Do not screw in the screws at this time) Note! The reflective film of the light-collecting plate must be protected during assembly.
2. Fix the square tube ring on the light collecting plate with MSx 15 screws, make sure that the square tube ring and the light collecting plate are in close contact during trapping, and tighten the screws.
3. Place the base on flat ground, screw the casing into the screw hole in the centre of the base, and screw it well.
4. Loosen the handle on the sleeve and poke the side of the cross with a long hole into the sleeve.
5. Two people picked up the light collecting plate, installed it on the cross, and fixed it with cotter pins. (Attention! The end with the sliding rod adjustment device must be upward)
6. One end of the sliding rod without a hole is inserted into the long hole on the square tube circle. The other end is inserted into the long hole of the cross, fixed with M8x35 screws. Then, the nut is adjusted while the light-collecting plate is moved up and down to tighten it correctly.
7. Insert the elbow into the upper hole of the cross and fix it with M6x 35 screws together with the support rod.
8. Install the other end of the cooker ring and support rod and fix them with screws.
9. While turning the light collecting plate left and right, adjust the handle on the base sleeve so that it is properly tightened.
10. Place the solar cooker where the wind will not affect the lighting and fix the base. At this point, the solar cooker has been assembled.
Specifications
Colour: Silver
Material: Iron
Surface Treatment: Spray Plastic Treatment, Aluminum Film
Fuel Type: Solar Energy
Thermal Power: 1000-1500W
Focal Spot Temperature: 800-1000°C/ 1472-1832°F
Stove Circle Diameter: 25.5cm/ 10.03in
Support Height: 115cm/ 45.27in
Solar Cooker Diameter: 150cm/ 59.05in
Package Size: 80*80*12cm/ 31.5*31.5*4.72in
Net Weight: 15kg/ 33.07lbs
Package Included
1* Concentrating Solar Cooker
3* Wheels
